Swiss Type CNC Head-back boring

Vendor:

型 號 EDP NO. ØK F W±0.03 L2 L r s ØD 在 庫 STOCK 適用套筒 Applicable Sleeve
37.4010-1002 4 3.5 1.0 10 40 0.2 0.8 4 SP.250-04**
SP.5650-04**
37.4015-1002 4 3.5 1.0 15 45 0.2 0.8 4 SP.250-04**
SP.5650-04**
37.5012-1202 5 3.8 1.2 12 45 0.2 1.2 4 SP.250-04**
SP.5650-04**
37.5018-1202 5 3.8 1.2 18 50 0.2 1.2 4 SP.250-04**
SP.5650-04**
37.6015-1502 6 4.8 1.5 15 50 0.2 1.5 6 SP.250-06**
SP.5650-06**
37.6022-1502 6 4.8 1.5 22 55 0.2 1.5 6 SP.250-06**
SP.5650-06**
37.7020-2002 7 5.8 2.0 20 55 0.2 2.0 6 SP.250-06**
SP.5650-06**
37.7025-2002 7 5.8 2.0 25 60 0.2 2.0 6 SP.250-06**
SP.5650-06**
37.8020-2002 8 6.8 2.0 20 60 0.2 2.5 8 SP.250-08**
SP.5650-08**
37.8035-2002 8 6.8 2.0 30 65 0.2 2.5 8 SP.250-08**
SP.5650-08**
10030-2502 10 8.5 2.5 30 75 0.2 2.5 10 SP.250-10**
SP.5650-10**
10040-2502 10 8.5 2.5 40 85 0.2 2.5 10 SP.250-10**
SP.5650-10**
無"●"標示者為訂製品。Without "●" marking means custom products.
有"●"標示者為在庫品。With "●" marking means items in stock.
